Description
About this item
- EASY INSTALLATION: Ready to go with support of native CCID drivers
- WIDE COMPLIANCE: Support of ALL major smart card types
- UPDATED: Rebrands the CLOUD line of smart card readers
- FAST: Data transmission speeds up to 600 Kbps
-
FITS IN YOUR POCKET: Conveniently carry with you to work or wherever
- Contact sales for stand holder for upright card insertion.
- SmartOS POWERED
- ERGONOMIC
Compliance
- ISO/IEC 7816
- USB CCID
- PC/SC
- Microsoft HCK
- Microsoft WHQL
- EMV 2008 Ver. 4.2 Level 1
- EMV Level 1
- GSA FIPS 201
- TA1=97
- Asynchronous smart card protocols T=0 & T=1
- CE
- FCC
- UL 60950
- VCCI
- RoHS2
- REACH
- WEEE
*Support for ALL relevant major industry standards*
Ideal For:
- Network log-on
- Windows Authentication
- Single Sign-on for PCs
- Banking and cashless payments
- High-security use cases for federal governments
- Very specific applications needing additional security and data protection
- Government
- Enterprise
- Home
- Large-scale deployments w/ contact smart cards/application software
- Distribution w/ smart cards, credit cards, e-IDs or software for online banking or digital signature applications
- Electronic ID
- Social Security
- Loyalty Programs
- e-Couponing
- Secure Network Log-on
- e-Banking
- Online Shopping
- Gaming activities
Features
- USB 2.0 Full Speed of 12 Mbps (Supports USB 1.1/3.0)
- Plug and Play
- PC/SC API
- CT-API
- M-Card
- Smart Card Interface Speed: 600 Kbps
- Smart Card Clock Frequency: Up to 12 MHz
- Card present switch
- Automatic power on/off
- Short circuit protection
- 8-Pin Handling: C4/C8 supported
- Card present switch
- Minimum insertion cycles: 100,000
- LED status indicator
- Device UID (Unique Identifier Number) to link reader and application together
- Multiple cable guides for flexible reader presentation
Card Support
- ALL MAJOR ISO/IEC compliant 7816 (Class A, B and C (5V, 3V and 1.8V) Smart and Synchronous Cards
- Asynchronous smart cards T=0 & T=1
- ID-1 (Full-size smart card)
*ALL MAJOR CONTACT SMART CARDS*
OS Support
- Windows XP/7/8/10/11 (32 and 64-bit versions)
- Windows Server 2008/2012/2016/2019
- MacOS 10.9.x-12.2.x
- Linux 2.4.x, 2.6.x, 3.x, 4.x, 5.x (32 and 64-bit versions)
Downloads Datasheet & Drivers
Identiv uTrust 2700 F USB 2.0 Type-A Contact Smart Card Reader Datasheet
Identiv uTrust 2700 F USB 2.0 Type-A Contact Smart Card Reader Driver Download Page
Steps for Downloading Drivers
- Click URL above titled Identiv uTrust 2700 F USB 2.0 Type-A Contact Smart Card Reader Driver Download Page
- Scroll down to uTrust 2700 F Contact Smart Card Reader
- Underneath Downloads header, select Driver based off current operating system and click Download>>
- Open file at the bottom of the web browser in the Download Bar (*Depending on browser i.e. Chrome, Edge or Firefox)
*To find out your operating system version for Windows, select File Explorer and right click This PC on the Quick Access left side panel and select Properties in the submenu. Underneath both Device specifications and Windows specifications, the OS version is stated.
